Development

So you want to get involved! The developers welcome community input. The central development area with all ServiceX repositories can be found here. The core steps are shown in the diagram below.

Development

Testing new changes

[Instructions for testing new changes. Broadly (1) setup testing environment via conda or virtualenv, (2) clone the appropriate repository, (3) run python -m pip install -e .[test] to set up the necessary packages in the environment, and (4) run the tests via pytests.]

Deploying ServiceX on a Kubernetes cluster

The entire ServiceX stack can be installed using the helm chart contained here. Below is a set of developer instructions for deploying a production-ready instance of ServiceX on a Kubernetes cluster.

Deployment requires access to a Kubernetes cluster. You’ll need to install and set up kubectl (see Install and Set Up kubectl) and Helm 3 (see Installing Helm).
Next configure kubectl to access the appropriate namespace on the cluster with the kubeconfig file located at ~/.kube/config.
For complete control over the deployment values in the ServiceX Helm chart, it’s recommended to check out the develop branch of ServiceX from GitHub:
```
git clone https://github.com/ssl-hep/ServiceX.git
cd ServiceX
git checkout develop
```

Add and update the ServiceX Helm chart:

helm repo add ssl-hep https://ssl-hep.github.io/ssl-helm-charts/
helm repo update
helm dependency update servicex

ServiceX may require some modifications to the default deployment values to run on your cluster. In particular, you’ll need your CERN grid certificate to communicate with Rucio. You can see the default values in servicex/values.yaml. These values can be overridden via a separate yaml file. For example, to run on SSL-RIVER,

cat <<EOF > river-values.yaml
app:
  auth: true
  adminUser: admin
  adminPassword: eto2ipiis1
  ingress:
    enabled: true
didFinder:
  tag: v1.0-rc.1
  pullPolicy: Always
codeGen:
  # image: sslhep/servicex_code_gen_func_adl_uproot
  image: sslhep/servicex_code_gen_func_adl_xaod
rabbitmq:
  service:
    type: NodePort
    nodePort: 30672
minio:
  ingress:
    enabled: true
    hosts:
    - "servicex-minio.uc.ssl-hep.org"
gridAccount: bgalewsk
EOF

With the appropriate values, it is now possible to deploy ServiceX via the Helm chart:
```
helm install -f river-values.yaml --version v1.0.0-rc.1 rc1-xaod ssl-hep/servicex
```

Initial deployment is typically rapid, with RabbitMQ requiring up to a minute to complete its initialization. After this all the pods of the new deployment should be ready. If you check the status of the pods via

kubectl get pods

You should soon find that your setup looks comparable to this:

NAME                                             READY   STATUS    RESTARTS   AGE
servicex-1579021789-code-gen-7cd998d5b6-nwtgv            1/1     Running   0          49m
servicex-1579021789-did-finder-7c5cbb4575-52wxf          1/1     Running   0          49m
servicex-1579021789-minio-78b55bfdf8-mbmmf               1/1     Running   0          49m
servicex-1579021789-preflight-b748b4dfd-qqt89            1/1     Running   4          49m
servicex-1579021789-rabbitmq-0                           1/1     Running   0          49m
servicex-1579021789-servicex-app-98779c79c-cvmqx         1/1     Running   3          49m
servicex-1579021789-x509-secrets-74f4bcc8bb-5kqvb        1/1     Running   0          49m

The new ServiceX deployment should now be ready for business. To try a 10TB scale test check ServiceX_scaleTest.
